PTZOptics PTVL-NDI-ZCAM • Box Camera with 4.4-88.5mm Lens • NDI|HX®, 3G-SDI, IP Streaming • 1080p60 • 28°-122° FOV (White)

Name: PTZOptics PTVL-NDI-ZCAM • Box Camera with 4.4-88.5mm Lens • NDI|HX®, 3G-SDI, IP Streaming • 1080p60 • 28°-122° FOV (White)
Brand: PTZOptics
SKU: CVSPTZ121
Price: 1247.0 AUD
Availability: InStock

SKU CVSPTZ121

Save 7%

$1,335.72

$1,335.72 - $1,335.72

$1,335.72

$1,247.00

$1,247.00 - $1,247.00

$1,247.00

14 Dec. Estimated arrival

11 Dec. Order placed

12-13 Dec. Order dispatches

14 Dec. Delivered!

For streaming broadcast-quality video at a concert, hospital, conference, or house of worship, the VL NDI|HX ZCam HD IP Network Camera from PTZOptics easily covers any event or location with a 4.4-88.5mm C/CS mount lens, a 4x zoom, and a video resolution up to 1080p60.

View more product information

features

Panasonic 1/2.7 inch 2.07MP HD CMOS sensor
4.4-88.5mm C/CS mount lens with 4x zoom and 28-122° field of view
Maximum of 1080p60 streaming video; two simultaneous streams possible with second stream maximum of 720p
IP streaming via RTSP and RTMP with H.265, H.264, and MJPEG compression
3G-SDI, ND|HX, Ethernet IP network outputs; 802.3af PoE (Power over Ethernet) supported
High SNR (signal-to-noise ratio) of ≥ 55 dB and wide DNR (dynamic range) to keep noise low and quality and detail high
Joystick or remote control over serial connection
Stream and configure camera over IP with web application
AC adapter, RS-232 cable, and IR remote controller included

specifications

Sensor	Panasonic 1/2.7" CMOS, 2.07 MP
Lens Mount	C/CS type
Power	Input Voltage: 12 VDC, JEITA-type power adapter Power over Ethernet (PoE): 802.3af PoE Current: 1.0 A max Power Consumption: 12 W max
Network Interface	Ethernet: 10/100/1000 Mb/s adaptive
Video Output	Interface: 1 x HD-SDI: BNC, 800 V p-p, 75 Ohms, SMPTE 424M standard Protocols: 3G-SDI, NDI\|HX, IP streaming
Frame Rates Supported	HD-SDI: 1080p: 60/50/30/25 1080i: 60/50/30/25 720p: 60/50/30/25 SD: NTSC, PAL
Video Codec Support	H.265, H.264, MJPEG dual stream output
Video Streaming	Protocols: NDI\|HX, TCP/IP, HTTP, RTSP, RTMP, multicast, DHCP, ONVIF Bit Rate: 128 to 8192 kb/s, fixed or variable Frame Rate: 50 Hz: 1 to 50 fps; 60 Hz: 1 to 60 fps
Audio Input / Output	In: 1 x 3.5 mm Out: 1 x 3.5 mm
Audio Encoding	Standard: AAC Bit Rate: 96, 128, 256 kb/s
Communication Port	Port Type: RS-485 Protocol: VISCA, Pelco-D, Pelco-P Max Distance: 0.75 mile / 1200 m
Supported Serial Port Baud Rates	2400/4800/9600 bits
Focal Length	4.42 to 88.5mm
Aperture Range	f1.8 to f2.8
Optical Zoom	4x
Shutter	1/30 sec, ~1/10000 sec
Minimum Lux	0.5 at f1.8, AGC ON
White Balance	Auto, indoor, outdoor, one push, manual, VAR
Horizontal Field of View (degree)	28° to 122°
Vertical Field of View (degree)	16° to 91°
Signal to Noise Ratio (SNR)	±55 dB
Mounting Thread	2 x 1/4"-20 female (top and bottom)
Operating Temperature	14 to 104°F / -10 to 40°C
Storage Temperature	-40 to 140°F / -40 to 60°C
Dimensions	2.4 x 5.7 x 3" / 6.1 x 14.5 x 7.6 cm
Weight	1.4 lb / 630 g

description

[Manual]

For streaming broadcast-quality video at a concert, hospital, conference, or house of worship, the VL NDI|HX ZCam HD IP Network Camera from PTZOptics easily covers any event or location with a 4.4-88.5mm C/CS mount lens, a 4x zoom, and a video resolution up to 1080p60. The camera can fit into any NDI-compatible setup, features a 1/2.7" CMOS sensor, and captures a 2.07 MP image with 3G-SDI and NDI|HX high definition output.

The camera connections include a 3G-SDI BNC connector, single-channel audio input and output, a RS-485 serial connector for remote communication, and an Ethernet port for IP streaming which features 802.3af PoE (Power over Ethernet). Broadcasting up to two streams simultaneously is supported; an HD stream with a maximum 1080p resolution, and a second SD stream with a maximum 720p resolution. A wired serial remote or web-based application can be used to connect and control, and the camera also features a joystick for local control of all the camera settings and operations.

With the optical 4x zoom lens, the horizontal field of view ranges from 28-122° with a maximum aperture of f1.8, which provides wide coverage and advanced low-light performance. Supported IP streaming protocols include RTSP and RTMP, AAC audio, H.265, H.264, and MJPEG compression. For greater image detail and quality in low light, the sensor's DRC (dynamic range control) assists in keeping your image sharp and balanced, and the high SNR (signal-to-noise ratio) reduces noise at ≥ 55 dB, particularly in low-light situations.

A 12 VDC power adapter, RS-232 cable, and IR remote are included in the package.

contents

PTZOptics PTVL-NDI-ZCAM • Box Camera with 4.4-88.5mm 4x Optical Zoom Lens
4x Zoom Lens
AC Power Adapter
Power Cord
RS-232 Cable
IR Remote Controller
Warranty

manufacturer

PTZOptics
