PTZOptics PT20X-NDI-ZCAM • Box Camera • 20x Optical • NDI|HX®, HD-SDI • 1080p • 2.3°-60.7° FOV (White)

Save 7% Save 7%
Original price $2,035.00
Original price $2,035.00 - Original price $2,035.00
Original price $2,035.00
Current price $1,899.00
$1,899.00 - $1,899.00
Current price $1,899.00

The PTZOptics PT20X-NDI-ZCAM is a 1080p box camera with 20X optical zoom for capturing HD video even at a distance.

Need help? Ask our experts for a quote or advice

  • Panasonic 1/2.7” HD CMOS Sensor
  • 3G-SDI High Definition Video Output
  • H.264, H.265 & MJPEG IP streaming output (dual stream)
  • AAC Audio Encoding over IP
  • High performance in low light scenarios
  • Full 1920x1080p HD Resolutions up to 60 frames per second via SDI
  • 2D & 3D noise reduction with PTZOptics latest “lownoise CMOS sensor”
  • Wide Dynamic Range
  • Menu controls on back of camera
  • RS485 and IP remote camera control
  • 60.7° Field of View
  • Std 1/4-20 female thread for camera mounting (bottom)
  • PoE (Power over Ethernet)


  • Camera & Lens:
    • Video Sensor: 1/2.7” CMOS, 2.12 Mega Pixels
    • Frame Rates: 1080p/60, 50, 30 & 25, 1080i/60 & 50, 720p/60, 50, 30 & 25
    • Focal Length: 20x, F4.42mm-88.5mm, F1.8-F2.8
    • Lens: Zoom 20x
    • Field of View: 60.7°
    • Min Lux: 0.5 Lux at F1.8, AGC ON
    • Shutter Speed 1/30s - 1/10000s
    • SNR: >/= 55dB
    • Vertical Flip & Mirror: Supported
    • Horizontal Field of View: 3.36° (tele) to 60.7° (wide)
    • Vertical Field of View: 1.89° (tele) to 34.1°(wide)
    • Working Environment: Indoor Box Weight 2.0 lbs | 0.90 kg
  • Rear Board Connectors:
    • Video Output Interface: 3G-SDI, NDI|HX
    • Communication Interface: RS485 VISCA, Pelco-D, Pelco-P
    • Baud Rate: 2400/4800/9600 bits
    • Power Supply Interface: JEITA type Power Adapter (DC in 12V)
  • Physical Specifications:
    • Dimensions (in.): 2.4 W x 5.7 D x 3.0 H
    • Dimensions (mm.): 60.9 W x 144.7 D x 76.2H
    • Camera Weight: 1.4 lbs | 0.63 kg



[Quick Start Guide]

The PTZOptics PT20X-NDI-ZCAM is a 1080p box camera with 20X optical zoom for capturing HD video even at a distance. With support for 3G-SDI & IP streaming, this camera is ideal for broadcasting high definition video signals for broadcast or video conferencing applications up to 1080p/60 resolution.

With built-in 3G-SDI and IP Streaming (w/ Power Over Ethernet), the ZCam models are easy to deploy. The included wide angle lens (ZCAM-VL) covers a massive 122 degree field of view and includes manual 4X optical zoom. The integrated 20X optical zoom ZCams offer a wide 60.7° FOV with a tight 3.36° field of view for ideal video imagery even at long distances. ZCAMS provide video professionals options inside their video production switchers. The ZCam models can be NDI™ upgraded or come native with NDI™ capabilities.


  • PTZOptics PT20X-NDI-ZCAM • Box Camera
  • Power Adapter
  • User Manual
  • Warranty
